Key Specifications: Conductor: 23 AWG Solid bare Copper Insulation: High Density Polyethylene Pairs: 2 Insulated conductors twisted together Shield: Aluminum / Polyester Foil Tinned copper Braiding Sheath: PVC / LSZH Cable Diameter: 7.5 mm nominal Electrical Properties: Conductor Resistance: โค 9.38 ฮฉ/100m Mutual Capacitance: < 5.6nF/100m Resistance Unbalance: 5% Max Capacitance Unbalance: 330pF/100m Delay Skew: < 45nS Mechanical Properties: Bending Radius: < 8 x Cable Diameter at โ20ยฐC ยฑ 1ยฐC Pulling Force: 11.5Kgs Temperature Range: โ20ยฐto +70ยฐC Connection System: Compatible with all common systems according to TIA/EIA 568.C.2 Applications: Enhanced performance cable for transmission of high speed data Digital and analogue voice and video (RGB) signals on LANs Supports Gigabit Ethernet (1000 baseT) standard Operates at bandwidth of 250 MHz. Tinned Copper Screening gives Protection against EMI and avoid signal loss. Better Mechanical Properties of Cable
